Specification
Model : CATL-3.2V 530Ah
Standard capacity: 530Ah
Nominal voltage: 3.2V
Battery internal resistance (1KHz)0.17±0.05mΩ
Battery weight9.3±0.3Kg
Battery size (Not include the studs)Height: 203±0.5 mm Length: 275±0.5 mm Thickness: 73±1.0 mm
Cell cycle≥8000cycles
Standard charging voltage3.65V
Discharge cut-off voltage2.5V
Standard charging current0.5C
Max charging current1C
Standard discharge current0.5C
Max discharge current1C
Charging temperature0~60°C
Discharging temperature-20~60°C
RemarkFor easy assembly, we will weld the M6 studs for the Lifepo4 battery. Each battery will send 1 pcs copper busbar and 2 pcs nuts.
